JVC KD-T92MBS Single DIN Marine MotorSports Bluetooth USB AUX AM/FM Radio Stereo Receiver with 4x Infinity Reference 6.5" Coaxial 225 Watt Waterproof White Marine LED Speakers (Bulk Packaging)

This JVC marine and motorsports receiver comes packed with all of the media options you need to take your vehicle's infotainment system to the next level. This receiver features CD playback and a classic AM/FM tuner so you can choose between listening to your own tunes and the radiowaves with ease. Bluetooth connectivity lets you conveniently connect your preferred handheld device to the receiver while the USB port allows for high current charging to keep your device powered all through your ride!

General Features:

• CD Receiver featuring Bluetooth
• AUX/USB Inputs
• Backlit Display
• Conformal Coated PCB
• 13-Band EQ
• 2-Zone Variable-Color Illumination
• JVC Remote App Compatibility
• 4.0V High-Voltage 3 Pre-Outs
• Space Enhancement
• Sound Response
• Sound Lift
• Audio Streaming & Control
• iPhone Bluetooth Automatic Pairing
• 2-Line VA LCD Display
• High Current 1.5A Charging
• Satellite Radio Ready
• Wired Remote Control (Optional)
• Steering Wheel Remote Control Ready
• AM/FM Tuner
• 18FM, 6AM Preset Stations
• MP3/WMA/WAV/AAC/FLAC Playback

Infinity Reference Marine Speakers are ready to take on your next outdoor adeventure. These fully marinized speakers not only deliver Infinty sound, but they also feature RGB lighting to bring the sound to life. Engineered to withstand sun, salt, sea spray and wash downs, they feature sealed motor structure, UV resistant one-piece cast-polymer baskets, a sealed magnet and rubber surrounds. The polypropyelene cone and balanced dome tweeter provide great bass, smooth highs and lots of output to ensure every note can be heard loud and clear.

General Features:

• 6-1/2" (160mm) two-way marine audio multi-element speaker(white)
• Seven color multi-color RGB LED lighting,included
• 225W Max
• Designed to withstand harsh outdoor environments
• Power Handling 75W RMS, 225W peak
• Sensitivity (@ 2.83V) 92dB
• Frequency Response 50Hz – 20kHz
• Impedance 4 ohms
• IPx5 Rated
• Cosmetic Appeal
• Outdoor Performance
• RGB Lighting
• Marine Design
• Balanced Dome Tweeters
• Designed for the Elements
• Harman Standard Reliability Testing
• Individually Voiced

Wiring Instructions:

Lighting is controlled manually through hardwire connection. Remove the adapter at the end of the speakers to expose the wiring. It will include a Black, Red, Green and Blue wire. When hard wiring the RGB lighting, the black lead is +12V and the Red/Green/Blue leads are ground (-) There are seven colors available through hardwire connection, select your color of choice and proceed with wiring it.

Note: These speakers do not come with gaskets or separate installation hardware.

+12V = Black
(-) Red = Red
(-) Green = Green
(-) Blue = Blue
(-) Red + Green = Lime Green
(-) Red + Blue = Magenta
(-) Blue + Green = Aquamarine
(-) Red + Blue + Green = Blue/White
