Infinity PRV-315.2 Marine Gauge Hole Mount USB Bluetooth AM/FM/WB Radio Receiver, Wired Remote, Extension, 4-Channel Amplifier w/Kit, 4x 6.5" 225W Multicolor LED Boat Speakers (White, Bulk Packaging)

---

Infinity PRV315.2 gauge style marine receiver has a waterproof face resistant to rain and splashing with a 3.5" Color-TFT screen display featuring an AM/FM radio tuner with 18 station presets, bluetooth audio streaming, a USB port for charging and playing MP3 audio, video input, 3 pairs of pre-outs including separate subwoofer output and Weatherband radio tuner.

General Features:

• AM/FM Bluetooth Audio Streaming
• 4 x 50 Watts
• Aux Input
• 3 1/2" cutout; 4 1/8" O.D.
• USB Input for USB Drives
• 3 Pair of RCA Pre-outs
• Charging Through USB
• Wired/Wireless Remote-Ready
• 6-Channel Preamp Outputs
• Marine-Grade Watertight Face

UPC Code 050667372873

---

Infinity Reference Marine Speakers are ready to take on your next outdoor adeventure. These fully marinized speakers not only deliver Infinty sound, but they also feature RGB lighting to bring the sound to life. Engineered to withstand sun, salt, sea spray and wash downs, they feature sealed motor structure, UV resistant one-piece cast-polymer baskets, a sealed magnet and rubber surrounds. The polypropyelene cone and balanced dome tweeter provide great bass, smooth highs and lots of output to ensure every note can be heard loud and clear.

6.5" LED Speakers:

• 6.5" Two-Way Marine Multi-Element speaker
• Seven color multi-color RGB LED lighting
• Power Handling 75W RMS, 225W peak
• Sensitivity: 92dB
• Frequency Response: 50Hz- 20kHz
• Impedance: 4 ohms
• IPx5 Rated

Wiring Instructions

Lighting is controlled manually through hardwire connection. Remove the adapter at the end of the speakers to expose the wiring. It will include a Black, Red, Green and Blue wire. When hard wiring the RGB lighting, the black lead is +12V and the Red/Green/Blue leads are ground (-) There are seven colors available through hardwire connection, select your color of choice and proceed with wiring it.

• +12V = Black
• (-) Red = Red
• (-) Green = Green
• (-) Blue = Blue
• (-) Red + Green = Lime Green
• (-) Red + Blue = Magenta
• (-) Blue + Green = Aquamarine
• (-) Red + Blue + Green = Blue/White

UPC Code 050667372910

---

Infinity M704A 4-Channel amplifier features selectable all high or low-pass crossovers with variable electronic frequency adjustment for precision system tuning. Engineered for harsh marine conditions with power and performance to meet the needs of any outdoor audio system. Max Power - 1000 Watts Peak

Amplifier:

• 4 Channel Marine Amplifier
• Class D Technology
• Max Power - 1000W Peak
• Power Output, 2Ω - 100W RMS x 4
• Power Output, 4Ω - 70W RMS x 4
• Power Output, 4Ω Bridged - 200W RMS x 2
• Signal-to-Noise Ratio - ≥85dB
• High and low level inputs
• Variable crossovers and bass boost

UPC Code 050667372729

---

This all weather wired remote provides the ability to control key source unit functions. Add localized control, with the most common area being the transom, quickly and easily! Arrives standard with 18" of cable so we suggest the REX20-6 extension for longer cabling needs. (REX20-6 is 20').

General Features:​

Control key source unit functions

Standard 18" cable

(Optional not included) REX20-6 extension - 20'

Compatible with the following Infinity source units

• INFPRV315.2
• REFPRV415
• KAPPRV515
• KAPMBB500

Dimensions:

• 4 1/8" L x 2 1/4" W x 1/2" (thickness once installed)
• 1 1/4" hole required for installation

UPC Code 648701578017

---

The REX20-6 extension cable gives you more placement options when you're installing select marine receivers and remotes. It features a 6-conductor plug, and if you have a long run to deal with, you can connect two of these extension harnesses for a total length of 40'.

Extension Cable

• 20-foot extension cable
• 6-conductor plug
• For use with REM-20,21,25,30,50 and 70

UPC Code 648701212003

---

The Power Sport Motorcycle Universal Amplifier Wiring Kit includes the following 6 foot length of red and black T-Spec OFC power and ground wire with a T-Spec V8MANL fuse holder, 60 amp fuse protected by a black nylon braid, Pre-terminated ring terminals, (2) 4 foot pieces of 16 gauge OFC speaker wire protected by black nylon mesh and 4"x6" hook and loop mounting pad for micro-amplifiers.

Amplifier Wiring Kit:

• Designed tor motorcycles
• 6 feet of red and black T-Spec OFC power and ground wire with a T-Spec V8MANL fuse holder and 60 amp fuse protected by a black nylon braid
• Pre-terminated ring terminals make connections to the battery simple
• Two 4 foot pieces of 16 gauge OFC speaker wire protected by black nylon mesh makes upgrading the factory speaker wires or adding new speakers a smart choice
• Upgrading Harmon Kardon System – Two 47-ohm .5 watt resistors to keep the factory radio outputs active
• All the necessary installation hardware is included along wtth a 4 × 6 inch hook and loop mounting pad for micro-amplifiers to hold the amplifier securely in place

UPC Code 086429332267
