Marine Audio MA100 Stereo, 4x 6.5" Black Boat Speakers, Amp w/Kit, USB Interface
There is no CD player in this unit, but it more than compensates with versatile connectivity to digital devices. Recharge via the USB port while you play digital music from smart phones, MP3 players and USB drives. Patch the audio in from your iPhone, iPod or any other source via the Aux audio inputs. Or stream your music wirelessly via Bluetooth.
The waterproof face is resistant to rain and splashing. With a full color dimmable display, this AM/FM radio receiver with 18 station presets, autotuning, and US/European frequency spacing is a complete audio product. Stream your music wirelessly from any Bluetooth compatible device. This receiver also features a rear USB port for charging and playing MP3 or WMA music files from smart phones.
General Features:
- AM/FM Bluetooth Audio Streaming
- 4 x 50 Watts
- Aux Input
- 3 1/2" cutout; 4 1/8" O.D.
- USB Input for USB Drives
- 3 Pair of RCA Pre-outs
- Charging Through USB
- Wired/Wireless Remote-Ready
- 6-Channel Preamp Outputs
- Marine-Grade Watertight Face
UPC Code 050667372873
Infinity's Marine speakers are constructed of solid, weather-resistant material, put together in the most careful, precise manner will provide you with a musical and listening experience that will keep you attached to your boat.
The Infinity 622M is the new 2016 replacement of the 612M/INF612M. The 6-1/2" speakers feature a polypropylene woofer cone bonded to a tough, UV-resistant rubber surround, which delivers full bass response and does a superb job deflecting sunlight and moisture. The corrosion-proof, cast-polymer basket resists deterioration from salt, moisture, and UV rays, while the stylish non-removable grille is specially meant for retaining its shiny chrome finish.
The grille-mounted 1" tweeter offers excellent high-frequency projection. Infinity seals the front of the woofer cone along with the speaker's magnet structure, serving as extra protection against moisture. Stainless steel mounting hardware is not included.
General Features:
- 2-way 6-1/2" marine speaker
- Power range: 2-75 watts RMS = 225 watts peak power.
- Polypropylene woofer cone with UV-resistant rubber surround.
- Grille-mounted 1" polypropylene semi-dome tweeter.
- Cast-polymer basket.
- Frequency response: 50-20,000 Hz.
- Sensitivity: 92 dB @ 2.83V.
- Top-mount depth: 2-5/8".
- Screws and hardware not included.
UPC Code 050667368951
This new weather-resistant amp; high-performance JBL Marine MA704 amplifier delivers impressive power from a compact chassis designed to withstand outdoor environments. With 4-channel outputs, this JBL Marine amplifier incorporates our latest amplifier topology that includes selectable all-, high-, or low-pass crossovers with variable electronic frequency adjustment for precision system tuning. Engineered for harsh marine conditions, with power and performance to meet the needs of any outdoor audio system, this amplifier is the perfect match for all of your JBL marine products.
Amplifier:
- 4 Channel Marine Amplifier
- Class D Technology
- Max Power - 1000W Peak
- Power Output, 2Ω - 100W RMS x 4
- Power Output, 4Ω - 70W RMS x 4
- Power Output, 4Ω Bridged - 200W RMS x 2
- Signal-to-Noise Ratio - ≥85dB
- High and low level inputs
- Variable crossovers and bass boost
UPC Code 050036346320
The Universal USB/3.5mm Auxiliary Interface Mount and Cable measures 10 feet in length and will convert your AUX inputs to USB.
AUX/USB Adaptor:
- USB to RCA pass-through extension cable
- Cable Length: 3m (10ft)
UPC Code 799861390145
Renegade REN10KIT 10mm^2 Car Audio Complete Amplifier Installation Wiring Kit
General Features:
- 1 x 10 mm^2 Power Wire (red), flexible Strands (0,15 mm), 5 m
- 1 x 10 mm^2 Ground Wire (grey), flexible Strands (0,15 mm), 0.8 m
- 1 x RCA Stereo Audio Cable (blue), double shielded, 5 m
- 1 x 0.5 mm^2 Remote Wire, 5 m
- 1 x AGU Fuse Holder with 40 A ANL Fuse
- Installation Kit
Installation Instructions:
- Disconnect at first the negative ground connection from the vehicle’s battery.
- Connect the GROUND CABLE (brown, 0.8m) with the ground terminal of the amplifier and a suitable GROUND contact point on the car chassis, with a maximum distance of 1 meter from the amplifier. Use the ringterminal for the GROUND contact point. Ensure that all paint or other insulation is removed from around the hole area.
- Find a suitable position for the FUSE HOLDER next to the car battery’s PLUS POLE. The maximum distance should not be more than 30 cm. Please ensure, that you don’t damage any parts of the car, like the fuel tank, wires etc.
- Cut off a part of the POWER CABLE (red, 5m) on one end, which has the same length like the distance from the battery’s PLUS POLE to the FUSE HOLDER (max. 30cm). Connect this part on the end without ringterminal with the FUSE HOLDER (without inserted fuse) and the other end to the battery’s PLUS POLE. Use for the connection the supplied ring terminals.
- Lead one end of the POWER CABLE (red) from the car battery area through the car to the +12V terminal of the amplifier and connect it. Then connect the other end of the cable with the FUSE HOLDER at the suitable terminal.
- Lead the RCA/CINCH CABLE pair with attached REMOTE WIRE from the HEAD UNIT through the car to the amplifier’s position. Then connect the RCA/CINCH plugs on one end with amplifier, and the other end with the HEAD UNIT RCA/CINCH outputs. Please observe the correct polarity of all connections.
- Connect the one end of the attached REMOTE WIRE with the REMOTE/REM terminal of the HEAD UNIT and the other end with the REMOTE/REM terminal of the amplifier. This wire provides a turn on/turn off signal to the amplifier, when the HEAD UNIT is turned on / turned off. NOTE: some amplifier types may require, that you have to extend the REMOTE WIRE with a suitable cable, to lead the REMOTE WIRE to the other endpanel of the amplifier.
- At least insert the FUSE into the FUSE HOLDER. Ensure not to cause a short circuit, or your car’s electric system may get damaged. Do not touch the bare metal parts of the cable or the car battery, otherwise a risk of electric shock consists. Then re-connect the negative ground connection to the vehicle’s battery.
UPC Code 854932002478
